New Contract with Verbund
This summer, we signed a contract with Verbund for 3 hydro
power plants:
1. Braunau-Simbach (GBR)
2. Schärding-Neuhaus (GSD)
3. Passau-Ingling (GPS)
The scope of supply consists of hydraulic development, model
testing and delivery of 12 Kaplan runners.
Technical characteristics:
3 x 4 vertical Kaplan Turbines
|
GBR
|
GSD
|
GPS
|
Turbine
nom. output
|
24 MW
|
23,1 MW
|
22,2 MW
|
Turbine min. output
|
3,8 MW
|
3,5 MW
|
3,6 MW
|
Rated net head
|
11,60 m
|
10,90
|
10,00
|
Max. discharge
|
300 m3/s
|
300 m3/s
|
300 m3/s
|
Min. discharge
|
40 m3/s
|
40 m3/s
|
40 m3/s
|
Rotational
speed
|
83 min-1
|
83 min-1
|
75 min-1
|
Runaway speed
|
210 min-1
|
200 min-1
|
206 min-1
|
Runner
diameter
|
6.300 mm
|
6.300 mm
|
6.300 mm
|
No. of
runner blades
|
4
|
4
|
4
|
Runner center line
|
336,70 m.a.s.l.
|
303,60 m.a.s.l.
|
292,26 ma.s.l.
|
Annual generation per HPP
|
623,84 GWh
|
606,79 GWh
|
561,51 GWh
|
This is already 11th Contract with Verbund.
Congratulations to the team, that was involved into offer
preparation and negotiations with the Client.
Dejan Lenart
Sales Director Assistant
